6CH AHD CCTV Kit Ahd Bullet Camera System 6 Channel Night Vision

Product Categories
Shenzhen Tollar Security Equipment Limited
Contact Now

6CH AHD CCTV Kit Ahd Bullet Camera System 6 Channel Night Vision

  • 1
  • 2

Brand Name : A-ZONE

Model Number : AZ-ahd camera kit k1

Certification : CE、FC、ROHS、IP66

Place of Origin : shenzhen

MOQ : 50pcs

Price : negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000000pcs/M

Delivery Time : depends on quantity

Packaging Details : carton packing, with air pocket, and we can design the box as your require

Day/Night : Auto(ICR)/Color/ B/W

Resolution : 1920*1080

Signal System : PAL\NTSC

Lens : 3.6mm Lens 36pcs ir leds

Power supply : DC12V±10%

Transmission Distance : Over 500M via 75~3 Coaxial Cable

Contact Now

6CH AHD CCTV Kit Ahd Bullet Camera System 6 Channel Night Vision

Camera Features:
(1) 1/4" CMOS image senor;
(2) 6CH 720P/960P/1080P AHD Kit optional;
(3) 3.6/6mm optional;
(4) IR distance 20-30M;
(5) metal dome 12IR leds. Metal bullet, 36 IR Leds.
(6) Can be widely used in 24 hours monitor sites such as hotels, factories, shopping malls, gas stations and so on.

DVR Features:
1. 8 Channel 1080N 4 in 1 ( AHD/TVI/CVI/CVBS)

2. HDMI 1080P output

3. Video input: 8CH BNC, 1CH VGA +1HDMI Output

4. Support Backup: USB 2.0 , Moved Hard Disk, USB,Writer, Network

5. Support 1*4TB

6. PC Monitoring software CMS & sellphone monitoring software MXEYE

IP66 waterproof

The HD surveillance cameras are extremely rugged and flexible.
Versatile ceiling or wall mounting options allows them to be placed wherever you need them most-indoors and outdoors.
They are IP66 rated and are able to withstand the most unforgiving climates.

AHD DVR kit Parameters:

Image Sensor 1/4" 2Megapixel CMOS HD AHD 1080P
Resolution 1920*1080
Min.illumination 0.002Lux F1.2(AGC ON),0Lux IR on
camera Features
Lens 3.6mm 2MP MRT
LED 36pcs ir LEDS
IR Range 10-30M
Day/Night Auto(ICR)/Color/ B/W
General
Power supply DC12V±10%
Transmission Distance Over 500M via 75~3 Coaxial Cable
Ingress Protection IP67

AHD DVR Data:

Model TL-CVD7004 TL-CVD7008
Display Interface 1 HDMI,1VGA,1BNC
Resolution 1920*1080,1280*1024,1280*720,1024*768,800*600
Display Split 1/4 1/4/8/
Privacy Masking 4 rectangular zones(each camera)
OSD camera title,Time,Video loss,Camera lock,Motion detection,Recording
Video/Audio compression H.264/G.711
Record Rate Main stream
Extra Stream		 720P/960H/D1/HD1/2CIF/CIF(1-25/30fps)
CIF/QCIF(1-25/30fps)
Record Mode Manual,Schedule(Regular(continuous),MD),Stop
Trigger Events Recording,PTZ,Tour,Video Push,Email,FTP,Spot,Buzzer&Screen
Video Detection Motion Detection,MD Zones:396(22/8),Video loss&camera Blank
Alarm Input 4 channel 8 channel
Sync Playback 1/4 1/4/8/
Search Mode Time/Date,MD&Exact search(accurate to second)
Backup Mode USB Device/network
Network Ethernet RJ-45 port(10/100M/1000M)
Max User Access 128 users
Smart Phone iphone,ipad,Android,Windows,Phone

66CH AHD CCTV Kit Ahd Bullet Camera System 6 Channel Night Vision
