| Camera Parameter | CPU | TI 368 |
| Image Sensor | 1/2.5" Prongressive Scan CMOS |
| Effective Pixel | 2.0 Mega Pixel(1920X1080) |
| Signal system | PAL/NTSC |
| Horizontal Resolution | ≥1000 TV lines |
| Video Format | 25 fps/1920*1080; 25fps/640*480;25fps@288*192 |
| Min. illumination | 0.5 Lux/F1.6(color);0.09 Lux/1.6(black & white);IR mode: OLux |
| Optical Zoom | 18X,auto focus |
| Focus Length | 4.5 ~85mm |
| Visual Angle | 55.4°~2.9° |
| Day & Night mode | Auto IR-CUT |
| PTZ Parameter | Rotation Speed | Horizontal 0.1°~40°/S;Vertical 0.1°-20°/S |
| Preset Speed | Horizontal 40°/S; Vertical 20°/S |
| Rotation Range | Horizontal 0°~360° unlimited rotation; Vertical 0°~90° auto 180° reversal |
| A-B two points scan | Random setting |
| A-B two points scan speed | Fast speed/Middle speed/Low speed, speed adjustable |
| Cruise No. | 8 groups(8 presets each group) |
| Presets | 128 |
| Alarm Input | 1ch |
| Alarm Output | 1ch |
| Power Memory | Support |
| Guard Position | Support |
| IR light | IR lights No. | F22 18pcs Array LED Lights,Effective distance up to 200m |
| Auto Control IR light | Auto IR-cut as per camera’s focus |
| Video Audio Alarm | Video Compression Format | H .264.; MPEG4 |
| Video Stream | Main Stream:1080P,Sub-stream:D1,CIF |
| Image Size | 1920*1080 |
| Audio Baud Rate | 64K bps |
| Voice Intercom | Support |
| Alarm | 1ch input,1ch output(optional) |
| Network Code | User Management | Max. Support 10 users |
| Network Protocol | TCP/IP,HTTP,DDNS,PPOE,NIP,FTP,RTSP,RTP |
| Access Protocol | Onvif Standard |
| Network interface | 1ch 10/100 Base T Ethernet,RJ45 interface |
| Remote Function | Support remote and remote upgrade |
| Web Service | Built-in Webserver Support IE |
| Network Bandwidth | 64 kbps-12Wbps |
| Spec. | Product Size | 4 inch |
| Shell | Aluminum Alloy |
| Bracket | Aluminum Alloy |
| power supply | DC12V5A (American /europe/Britain) |
| Power | 40W(without heater)/70W(with heater) |
| Working Temperature | -25°C~70°C(without heater)/-50°C~70°C(with heater) |
| Install Method | Wall and Ceiling ( standard is wall ) |
| Packing | Size | 295mm×295mm×410mm |
| Weight | 6.0Kg |
| Size (Two package to one carton) | 610mm×315mm×430mm |
| Weight (Two package to one carton) | 13.0Kg |
